Enterasys Matrix DFE-Gold Series User Manual

set lldp port tx-tlv Link Layer Discovery Protocol and LLDP-MED
Enterasys Matrix DFE-Gold Series Configuration Guide 3-31
Parameters
all AddalloptionalTLVstotransmittedLLDPDUs.
port‐desc PortDescriptionoptionalbasicLLDPTLV.ValuesentisifDescrobject
definedinRFC2863.
sys‐name SystemNameoptionalbasicLLDPTLV.Valuesentisthe
administrativelyassignednameforthesystem.
sys‐desc SystemDescriptionoptionalbasicLLDPTLV.Valuesentis
sysDescr
objectdefinedinRFC3418.
sys‐cap SystemCapabilitiesoptionalbasicLLDPTLV.Foranetwork
connectivitydevice,valuesentcanbebridgeand/orrouter.
mgmt‐addr ManagementAddressoptionalbasicLLDPTLV.ValuesentisIPv4
addressofhostinterface.
vlan‐id PortVLANIDIEEE802.1ExtensionsTLV.Valuesentis
portVLANID
(PVID).
stp SpanningTreeinformationdefinedbyProtocolIdentityIEEE802.1
ExtensionsTLV.IfSTPisenabledontheport,valuesentinclud es
versionof protocolbeingused.
lacp LACPinformationdefinedbyProtocolIdentityIEEE802.1Extensions
TLV.IfLACPisenabledontheport,valuesentincludes
versionof
protocolbeingused.
gvrp GVRPinformationdefinedbyProtocolIdentityIEEE802.1Extensions
TLV.IfLACPisenabledontheport,valuesentincludesversionof
protocolbeingused.
mac‐phy MAC‐PHYConfiguration/StatusIEEE802.3ExtensionsTLV. Valuesent
includestheop erationalMAUtype,duplex,andspeedoftheport.
poe PowerviaMDIIEEE802.3ExtensionsTLV.Valuessentincludewhether
pairselectioncanbecontrolledonport,andthepowerclasssupplied
bytheport.OnlyvalidforPoE‐enabledports.
link‐aggr LinkAggregationIEEE802.3ExtensionsTLV.Valuessentindicate
whetherthelinkassociatedwiththisportcan
beaggregated,whetherit
iscurrentlyaggregated,andifaggregated,theaggregatedport
identifier.
max‐frame MaximumFrameSizeIEEE802.3ExtensionsTLV.Valuesentindicates
maximumframesizeoftheport’sMACandPHY.
med‐cap LLDP‐MEDCapabilitiesTLV.Valuesentindicatesthecapabilities
(whetherthedevicesupportslocationinformation,networkpolicy,

extendedpowerviaMDI)andDeviceType(networkconnectivity
device)ofthesendingdevice.
med‐pol LLDP‐MEDNetworkPolicyTLV.Valuessentincludeapplicationname,
VLANtype(taggedoruntagged),VLANID,andbothLayer2and
Layer3prioritiesassociatedwithapplication,forallapplications
enabledontheport.
Seethesetlldpportnetwork‐policycommandfor
moreinformation.
med‐loc LLDP‐MEDLocationIdentificationTLV.ValuesentistheECSELIN
valueconfiguredontheport.Seethesetlldpportlocation‐info
commandformoreinformation.
