Enterasys Matrix DFE-Gold Series User Manual

set lldp port network-policy Link Layer Discovery Protocol and LLDP-MED
Enterasys Matrix DFE-Gold Series Configuration Guide 3-33
Defaults
None.
Mode
Switchcommand,Read‐Write.
Usage
AsdescribedintheANSI/TIAStandardsdocument1057,theNetworkPolicyTLVis“intendedfor
usewithapplicationsthathavespecificreal‐timenetworkpolicyrequirements,suchasinteractive
voiceand/orvideoservices”andshouldbeimplementedonlyondirectlinksbetweennetwork
connectivitydevicesandendpointdevices.Refertothe
ANSI/TIAStandardsdocument1057for
descriptionsoftheapplicationtypes.
AfteryouconfigureNetworkPolicyTLVs,youmustalsoconfiguretheporttosendtheNetwork
PolicyTLVwiththesetlldpporttx‐tlvcommand.
ThepoliciesconfiguredwiththiscommandaresentinLLDPDUsasLLDP‐MEDNetworkPolicy
TLVs.MultipleNetworkPolicyTLVscanbesentinasingleLLDPDU.
Example
ThisexampleconfiguresthevoiceapplicationTLVonportfe.2.1andthenconfigurestheportto
sendtheNetworkPolicyTLV.
Matrix(rw)->set lldp port network-policy voice state enable tag tagged vlan dot1p
fe.2.1
Matrix(rw)->set lldp port tx-tlv med-pol fe.2.1
stateenable|disable (Optional)Enablesordisablesadvertisingtheapplicationinformation
beingconfigured.
tagtagged|untagged (Optional)Indicateswhethertheapplicationbeingconfiguredisusinga
taggedoruntaggedVLAN.Ifuntagged,boththeVLANIDandtheCoS
priorityfieldsareignoredandonlytheDSCPvaluehasrelevance.
vid
vlan‐id|dot1p (Optional)VLANidentifierfortheport.Thevalueofvlan-idcanrange
from1to4094.
Use dot1p if the device is using priority tagged frames, meaning that
only the IEEE 802.1D priority level is significant and the default PVID
of the ingress port is used.
coscos‐value (Optional)SpecifiestheLayer2prioritytobeusedfortheapplication
beingconfigured.Thevaluecanrangefrom0to7.Avalueof0
representsuseofthedefaultpriorityasdefinedinIEEE802.1D.
dscpdscp‐value (Optional)SpecifiestheDSCPvaluetobeusedto
provideDiffservnode
behaviorfortheapplicationbeingconfigured.Thevaluecanrange
from0to63.Avalueof0representsuseofthedefaultDSCPvalueas
definedinRFC2475.
port‐string Specifiestheportorrangeofportstobeaffected.
