Quad Serial Peripheral Interface (QuadSPI)
MPC5606S Microcontroller Reference Manual, Rev. 7
Freescale Semiconductor 1011
Table 30-15. After SCK Delay Scaler
ASC After SCK Delay Scaler Value ASC After SCK Delay Scaler Value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 30-16. After Transfer Scaler
DT
Delay after Transfer Scaler
Value
DT
Delay after Transfer Scaler
Value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 30-17. Baud Rate Scaler
BR Baud Rate Scaler Value BR Baud Rate Scaler Value
0000 2 1000 256
0001 4 1001 512
0010 6 1010 1024
0011 8 1011 2048
0100 16 1100 4096
0101 32 1101 8192
0110 64 1110 16384
0111 128 1111 32768
