Reset Generation Module (MC_RGM)
MPC5606S Microcontroller Reference Manual, Rev. 7
1082 Freescale Semiconductor
31.3.1.5 Functional Event Alternate Request Register (RGM_FEAR)
This register defines an alternate request to be generated when a reset on a functional event has been
disabled. The alternate request can be either a Safe mode request to MC_ME or an interrupt request to the
system. It can be accessed in read/write in either supervisor mode or test mode. It can be accessed in read
only in user mode.
Table 31-6. Destructive Event Reset Disable Register (RGM_DERD) field descriptions
Field Description
D_LVD27 Disable 2.7V low-voltage detected
0 A 2.7V low-voltage detected event triggers a reset sequence
1 A 2.7V low-voltage detected event generates either a Safe mode or an interrupt request depending on the
value of RGM_DEAR.AR_LVD27
D_SWT Disable software watchdog timer
0 A software watchdog timer event triggers a reset sequence
1 A software watchdog timer event generates either a Safe mode or an interrupt request depending on the value
of RGM_DEAR
D_LVD12_P
D1
Disable 1.2V low-voltage detected (power domain #1)
0 A 1.2V low-voltage detected (power domain #1) event triggers a reset sequence
1 A 1.2V low-voltage detected (power domain #1) event generates either a Safe mode or an interrupt request
depending on the value of RGM_DEAR.AR_LVD12_PD1
D_LVD12_P
D0
Disable 1.2V low-voltage detected (power domain #0)
0 A 1.2V low-voltage detected (power domain #0) event triggers a reset sequence
1 A 1.2V low-voltage detected (power domain #0) event generates either a Safe mode or an interrupt request
depending on the value of RGM_DEAR.AR_LVD12_PD0
Address 0xC3FE_4010 Access: Supervisor read/write
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R
AR_EXR
AR_FLASH
AR_LVD45
AR_CMU0_FHL
AR_CMU0_OLR
AR_FMPLL0
AR_CHKSTOP
AR_SOFT
AR_CORE
AR_JTAG
W
POR 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 31-6. Functional Event Alternate Request Register (RGM_FEAR)
Table 31-7. Functional Event Alternate Request Register (RGM_FEAR) field descriptions
Field Description
AR_EXR Alternate Request for External Reset
0 Generate a Safe mode request on an external reset event if the reset is disabled
1 Generate an interrupt request on an external reset event if the reset is disabled
AR_FLASH Alternate Request for code or data flash fatal error
0 Generate a Safe mode request on a code or data flash fatal error event if the reset is disabled
1 Generate an interrupt request on a code or data flash fatal error event if the reset is disabled
