LIN Controller (LINFlex)
MPC5606S Microcontroller Reference Manual, Rev. 7
Freescale Semiconductor 859
23.7.2.18 Identifier filter match index (IFMI)
This register is not implemented on LINFlex_1.
FACT[1] 0 Filters 2 and 3 are deactivated.
1 Filters 2 and 3 are activated.
FACT[2] 0 Filters 4 and 5 are deactivated.
1 Filters 4 and 5 are activated.
FACT[3] 0 Filters 6 and 7 are deactivated.
1 Filters 6 and 7 are activated.
FACT[4] 0 Filters 8 and 9 are deactivated.
1 Filters 8 and 9 are activated.
FACT[5] 0 Filters 10 and 11 are deactivated.
1 Filters 10 and 11 are activated.
FACT[6] 0 Filters 12 and 13 are deactivated.
1 Filters 12 and 13 are activated.
FACT[7] 0 Filters 14 and 15 are deactivated.
1 Filters 14 and 15 are activated.
Address: Base + 0x0044 Access: User read-only
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R 0 0 0 0 0 0 0 0 0 0 0 IFMI[0:4]
W
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 23-24. Identifier filter match index (IFMI)
Table 23-25. IFMI field descriptions
Field Description
0:26 Reserved
Table 23-24. IFER[FACT] configuration (continued)
Bit Value Result
