LCD Driver (LCD64F6B)
MPC5606S Microcontroller Reference Manual, Rev. 7
810 Freescale Semiconductor
22.4.2.19 LCDRAM (Location 13)
Address: Base + 0x54 Access: User read/write
0 1 2 3 4 5 6 7
R 0 0
FP52BP5 FP52BP4 FP52BP3 FP52BP2 FP52BP1 FP52BP0
W
Reset 0 0 0 0 0 0 0 0
8 9 10 11 12 13 14 15
R 0 0
FP53BP5 FP53BP4 FP53BP3 FP53BP2 FP53BP1 FP53BP0
W
Reset 0 0 0 0 0 0 0 0
16 17 18 19 20 21 22 23
R 0 0
FP54BP5 FP54BP4 FP54BP3 FP54BP2 FP54BP1 FP54BP0
W
Reset 0 0 0 0 0 0 0 0
24 25 26 27 28 29 30 31
R 0 0
FP55BP5 FP55BP4 FP55BP3 FP55BP2 FP55BP1 FP55BP0
W
Reset 0 0 0 0 0 0 0 0
Figure 22-20. LCDRAM (Location 13)
Table 22-24. LCDRAM (Location 13) field descriptions
Field Description
0:31 FP[52:55]BP[5:0]. LCD segment ON.
The FP[52:55]BP[5:0] bit displays (turns on) the LCD segment connected between FP[52:55] and BP[5:0].
0 LCD segment OFF
1 LCD segment ON
