NXP Semiconductors MPC5606S - Memory Map

Memory Map
MPC5606S Microcontroller Reference Manual, Rev. 7
Freescale Semiconductor 77
0xC3F8C000 0xC3F8FFFF 16 Ye s Ye s Ye s Data Flash 0 Configuration
(DFLASH0)
0xC3F90000 0xC3F93FFF 16 Ye s Ye s Ye s System Integration Unit Lite (SIUL)
0xC3F94000 0xC3F97FFF 16 Ye s Ye s Ye s WakeUp Unit (WKPU)
0xC3F98000 0xC3F9FFFF 32 — — — Reserved
0xC3FA0000 0xC3FA3FFF 16 Ye s Ye s Ye s Enhanced Modular I/O Subsystem 0
(eMIOS0)
0xC3FA4000 0xC3FA7FFF 16 Ye s Ye s Ye s Enhanced Modular I/O Subsystem 1
(eMIOS1)
0xC3FA8000 0xC3FAFFFF 32 — — — Reserved
0xC3FB0000 0xC3FB3FFF 16 No No Ye s Code Flash 1 Configuration
(CFLASH1)
0xC3FB4000 0xC3FD7FFF 144 — — — Reserved
0xC3FD8000 0xC3FDBFFF 16 Ye s Ye s Ye s System Status and Configuration
Module (SSCM)
0xC3FDC000 0xC3FDFFFF 16 Ye s Ye s Ye s Mode Entry Module (MC_ME)
0xC3FE0000 0xC3FE3FFF 16 Ye s Ye s Ye s Clock Generation Module (MC_CGM,
XOSC, IRCOSC, FMPLL_0,
FMPLL_1, CMU0, CMU1)
0xC3FE4000 0xC3FE7FFF 16 Ye s Ye s Ye s Reset Generation Module (MC_RGM)
0xC3FE8000 0xC3FEBFFF 16 Ye s Ye s Ye s Power Control Unit (MC_PCU)
0xC3FEC000 0xC3FEFFFF 16 Ye s Ye s Ye s Real Time Counter (RTC/API)
0xC3FF0000 0xC3FF3FFF 16 Ye s Ye s Ye s Periodic Interrupt Timer (PIT/RTI)
0xC3FF4000 0xC3FFFFFF 48 — — — Reserved
PBRIDGE(0) — Off Platform Peripherals (new range)
0xFFE00000 0xFFE03FFF 16 Ye s Ye s Ye s Analog to Digital Converter 0 (ADC0)
0xFFE04000 0xFFE2FFFF 176 O Reserved
0xFFE30000 0xFFE33FFF 16 Ye s Ye s Ye s Inter-IC Bus Interface Controller 0
(I
2
C0)
Table 2-1. MPC5606S system memory map (continued)
AP
Size
[KB]
5602S 5604S 5606S
Region
1
Start
Address
End Address
