31.3.1.6 Destructive Event Alternate Request Register (RGM_DEAR)
This register defines an alternate request to be generated when a reset on a destructive event has been
disabled. The alternate request can be either a Safe mode request to MC_ME or an interrupt request to the
system. It can be accessed in read/write in either supervisor mode or test mode. It can be accessed in read
only in user mode.
AR_LVD45 Alternate Request for 4.5V low-voltage detected
0 Generate a Safe mode request on a 4.5V low-voltage detected event if the reset is disabled
1 Generate an interrupt request on a 4.5V low-voltage detected event if the reset is disabled
AR_CMU0_F
HL
Alternate Request for CMU0 clock frequency higher/lower than reference
0 Generate a Safe mode request on a CMU0 clock frequency higher/lower than reference event if the reset is
disabled
1 Generate an interrupt request on a CMU0 clock frequency higher/lower than reference event if the reset is
disabled
AR_CMU0_
OLR
Alternate Request for FXOSC frequency lower than reference
0 Generate a Safe mode request on a FXOSC frequency lower than reference event if the reset is disabled
1 Generate an interrupt request on a FXOSC frequency lower than reference event if the reset is disabled
AR_FMPLL0 Alternate Request for FMPLL0 fail
0 Generate a Safe mode request on a FMPLL0 fail event if the reset is disabled
1 Generate an interrupt request on a FMPLL0 fail event if the reset is disabled
AR_CHKST
OP
Alternate Request for checkstop reset
0 Generate a Safe mode request on a checkstop reset event if the reset is disabled
1 Generate an interrupt request on a checkstop reset event if the reset is disabled
AR_SOFT Alternate Request for software reset
0 Generate a Safe mode request on a software reset event if the reset is disabled
1 Generate an interrupt request on a software reset event if the reset is disabled
AR_CORE Alternate Request for core reset
0 Generate a Safe mode request on a core reset event if the reset is disabled
1 Generate an interrupt request on a core reset event if the reset is disabled
AR_JTAG Alternate Request for JTAG initiated reset
0 Generate a Safe mode request on a JTAG initiated reset event if the reset is disabled
1 Generate an interrupt request on a JTAG initiated reset event if the reset is disabled
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R
0
AR_LVD27
AR_SWT
AR_LVD12_PD1 AR_LVD12_PD0
W
POR 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Figure 31-7. Destructive Event Alternate Request Register (RGM_DEAR)
Table 31-7. Functional Event Alternate Request Register (RGM_FEAR) field descriptions (continued)
Field Description
