Deserial Serial Peripheral Interface (DSPI)
MPC5606S Microcontroller Reference Manual, Rev. 7
298 Freescale Semiconductor
0100 5 1100 13
0101 6 1101 14
0110 7 1110 15
0111 8 1111 16
Table 11-8. DSPI PCS to SCK delay scaler
CSSCK PCS to SCK delay scaler value CSSCK PCS to SCK delay scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 11-9. DSPI after SCK delay scaler
ASC After SCK delay scaler value ASC After SCK delay scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
0100 32 1100 8192
0101 64 1101 16384
0110 128 1110 32768
0111 256 1111 65536
Table 11-10. DSPI delay after transfer scaler
DT Delay after transfer scaler value DT Delay after transfer scaler value
0000 2 1000 512
0001 4 1001 1024
0010 8 1010 2048
0011 16 1011 4096
Table 11-7. DSPI Transfer frame size (continued)
FMSZ Frame size FMSZ Frame size
