Interrupt Controller (INTC)
MPC5606S Microcontroller Reference Manual, Rev. 7
Freescale Semiconductor 765
22 0x0858 4 X Channel 11 DMA2x
23 0x085C 4 X Channel 12 DMA2x
24 0x0860 4 X Channel 13 DMA2x
25 0x0864 4 X Channel 14 DMA2x
26 0x0868 4 X Channel 15 DMA2x
27 0x086C 4 Reserved
28 0x0870 4 X Timeout Software Watchdog (SWT)
29 0x0874 4 Reserved
30 0x0878 4 X Match on channel 0 STM
31 0x087C 4 X Match on channel 1 STM
32 0x0880 4 X Match on channel 2 STM
33 0x0884 4 X Match on channel 3 STM
34 0x0888 4 Reserved
35 0x088C 4 X ECC_DBD_PlatformFlash |
ECC_DBD_PlatformRAM
ECSM
36 0x0890 4 X ECC_SBC_PlatformFlash |
ECC_SBC_PlatformRAM
ECSM
37 0x0894 4 Reserved
Section C
38 0x0898 4 X RTC Real Time Counter (RTC/API)
39 0x089C 4 X API Real Time Counter (RTC/API)
40 0x08A0 4 Reserved
41 0x08A4 4 X SIU External IRQ_0 System Integration Unit Lite (SIUL)
42 0x08A8 4 X SIU External IRQ_1 System Integration Unit Lite (SIUL)
43 0x08AC 4 Reserved
44 0x08B0 4 Reserved
45 0x08B4 4 Reserved
Table 21-10. Interrupt vector table (continued)
IRQ # Offset
Size
[Byte]
This Device
Resource Module
