Enterasys Matrix DFE-Gold Series

Configuring VRRP create
21-62 Routing Protocol Configuration
Usage
YoumustexecutetheroutervrrpcommandtoenabletheprotocolbeforecompletingotherVRRP‐
specificconfigurationtasks.Fordetailsonenablingconfigurationmodes,refertoTable 2‐8in
“EnablingRouterConfigurationModes”onpage 2‐103.
The“no”formofthiscommandremovesallVRRPconfigurationsfromtherunningconfiguration.
Example
ThisexampleshowshowenableVRRPconfigurationmode:
Matrix>Router#configure terminal
Matrix>Router(config)#router vrrp
Matrix>Router(config-router)#
create
UsethiscommandtocreateaVRRPsession.
Syntax
create vlan vlan-id vrid
no create vlan vlan-id vrid
Parameters
Defaults
None.
Mode
Routercommand,Routerconfiguration:Matrix>Router(config‐router)#
Usage
ThiscommandmustbeexecutedtocreateaninstanceofVRRPonaroutinginterface(VLAN)
beforeanyotherVRRPsettingscanbeconfigured.
EachEnterasysMatrixSeriesGoldroutingmodulesupportsupto128VRRPsessions.Uptofour
VRIDscanbeassociatedwithanindividualroutinginterface.
The“no”form
ofthiscommanddisablestheVRRPsession.
Example
ThisexampleshowshowtocreateaVRRPsessiononVLAN1withaVRIDof1:
Matrix>Router(config)#router vrrp
Matrix>Router(config-router)#create vlan 1 1
vlanvlan‐id SpecifiesthenumberoftheVLANonwhichtocreateaVRRPsession.
ThisVLANmustbeconfiguredforIProutingasdescribedin“Pre‐
RoutingConfigurationTasks”onpage 2‐100.
vrid SpecifiesauniqueVirtualRouterID(VRID)toassociatewiththe
routinginterface.Thevalueof
vridcanrangefrom1to255.
