SearchFH/FZ5 Processing Item Function Reference Manual
103
2
Inspecting and Measuring
3 When the setting has been changed,
click [Measure] in the Detail area to
verify whether measurements can be
made correctly.
4 Set up the judgement condition.
Sort condition
• Corr. ascending
•[Corr.
de
sce
nding]
• X coordinate
ascending
• X coordinate
de
sce
nding
• Y coordinate
ascending
• Y coordinate
de
sce
nding
Specify the conditions by which the search number is re-assigned.
When sorting referencing the X and Y coordinates, the upper left is the
origi
n
.
Search No.
0 to 127
[0]
Specify which of the multiple detection results will be used as measured
result
s.
• The values beside each item are measurement results of the
displayed image. Take these values into
consideration to determine the upper and lower limit values.
Setting item Set value Description
Count 0 to 128 Specify the number of detections that are judged to be OK.
Measure X -99999.9999 to 99999.9999 Specify the range of X-axis shifting that is
j
udged to be OK.
Measure Y -99999.9999 to 99999.9999 Specify the range of Y-axis shifting
that is judged to be OK.
Search angle -180 to 180 Specify the range of angles that are judged to be OK.
Correlation 0 to 100
S
pecify the range of correlation values that are judged to be
OK. Ho
wever, when the correlation value of the measurement
result is 0, the judgement result will be NG regardless of the
lower limit setting.
Setting item
Set value
[Factory default]
Description
Note
