2D Code
418
FH/FZ5 Processing Item Function Reference Manual
Region Setting (2D Code)
Specify the rectangular area in which to search for 2D Code.
Restricting the measurement range can shorten the processing time.
1 In the Item Tab area, click [Region setting].
2 Click [Edit].
The figure setting area is displayed.
3 Specify the area in which to search for 2D Code.
The rectangle covering the entire screen is set. Adjust the size and position of the rectangle.
4 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
Measurement Parameters (2D Code)
This item specifies the judgement conditions for measurement conditions and measurement results.
When the [Teaching] button is pressed, det
ailed settings are set automaticaly.
If you then click the [Measurement] button, measurement is ex
ecuted, the detected 2D Code region is displayed
on the image and the measurement results are displayed as measurement value of the judgement condition.
If measurement cannot be carried out successfully with this pr
oced
ure, adjust the parameters shown below.
1 In the Item Tab area, click [Measurement].
2 Select the read mode.
Measurement
This item specifies the judgement condition for measur
ement results. Set the code type and the number of
characters to be judged as OK.
Reference: Measurement Parameters (2D Code) (p.418)
Result setting
Set the measurement results. Judgement results can be classified.
Reference: Results Settings (2D Code) (p.422)
Output
p
arameter
This item can be changed if necessary. Normally, the factory default value will be used.
Reference: Output Parameters (2D Code) (p.422)
•
Normal (DataMatrix/QRCode/MicroQR/PDF417/MicroPDF417):
Set the measurement region to be 1600 × 1200 or less.
• DPM mode (DataMatrix/QRCode):
Set the measurement region to be 2448 × 2044 or less.
• Set the measurement region such that
it contains only 1 2D Code.
If there is more than one 2D Code in the measurement regio
n, measurement may not be performed correctly.
Setting item
Set value
[Factory default]
Description
Read mode
• [Normal]
•DPM
Usually, set this to "Normal".
Select DPM to read 2D code to which direct parts marking (DPM) was
ap
plie
d.
Item name Description
To Next Page
