Circle AngleFH/FZ5 Processing Item Function Reference Manual
493
2
Inspecting and Measuring
External Reference Tables (Circle Angle)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Center position X Get only 0 to 99999.9999
6 Center position Y Get only 0 to 99999.9999
7 Rotation angle Get only -180 to 180
8 Reference X Get only 0 to 99999.9999
9 Reference Y Get only 0 to 99999.9999
10 Reference angle Get only -180 to 180
101 Output coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
120 Mode Set/Get
0: Search
1: Edge
2: Defect
121 Skipping angle Set/Get 0.1 to 10
122 Edge pitch Set/Get 1 to 99
