EC Circle Search
146
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (EC Circle Search)
Set up EC circle search according to the following steps.
List of EC Circle Search Items
EC circle search items are explained below.
Item name Description
Circle setting
This item sets the size of the circle to
search for.
Reference: Circle Setting (EC Circle Search) (p.147)
Region setting
This item is used to set up the measurement area.
Narrowing the measurement area instead of measuring th
e entire input screen shortens the processing
time.
Reference: Region Setting (EC Circle Search) (p.148)
Ref. setting
This item can be changed if necessary.
Usually, the central position of th
e
registered region is specified as the reference position.
Reference: Reference Setting (EC Circle Search) (p.148)
Color setting
This item can be changed if necessary.
Select the color of the circle and the background color. If no check is pla
ced at color setting, the circle
(edge) is extracted with the brightness difference.
Reference: Color Specification (EC Circle Search) (p.149)
Measurement
pa
rameter
This item changes the measurement parameter as necessary when the measurement result is unstable.
Reference: Measurement Parameters (EC Circle Search) (p.150)
Output
pa
rameter
This item can be changed if necessary.
Normally, the factory default value will be used. Use th
e output parameter to specify how to handle the
coordinates.
Reference: Output Parameters (EC Circle Search) (p.152)
Be sure to perform settings Perform as necessary
Results confirmation/adjustment
▲
Circle Setting (EC circle search)
▲
Region Setting (EC circle search)
Start
Settings complete
Test measurement
▲
Reference Setting (EC circle search)
▲
Measurement Parameters (EC circle search)
▲
Output Parameters (EC circle search)
▲
Color Specification (EC circle search)
To Next Page
