DefectFH/FZ5 Processing Item Function Reference Manual
365
2
Inspecting and Measuring
External Reference Tables (Defect)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Defect Get only 0 to 999
6 Position X Get only 0 to 99999.9999
7 Position Y Get only 0 to 99999.9999
8 Defect area Get only 0 to 999999999.9999
9 Defect gravity X Get only 0 to 99999.9999
10 Defect gravity Y Get only 0 to 99999.9999
103
Reflect to overall
j
udg
ement
Set/Get
0: ON
1: OFF
120 Upper limit of defect size Set/Get
0: 4
1: 8
2: 12
3: 16
4: 24
5: 32
6: 64
121 Lower limit of defect size Set/Get
0: 4
1: 8
2: 12
3: 16
4: 24
5: 32
6: 64
122
Upper limit of defect
j
udgement
Set/Get 0 to 999
123 Defect color Set/Get
0: Both
1: White
2: Black
124 Area measurement Set/Get
0: OFF
1: ON
125 Area meas, LV Set/Get 0 to 999
126
Upper limit of area
j
udg
ement
Set/Get 0 to 999999999.9999
127
Lower limit of area
j
udg
ement
Set/Get 0 to 999999999.9999
128
Lower limit of defect
j
udgement
Set/Get 0 to 999
150 Region reverse Set/Get
0: Not reverse
1: Reverse
151 Dilate erosion level Set/Get -10 to 10
152 Static mask type Set/Get
0: Region extract
1: Region of image reference
