Character InspectionFH/FZ5 Processing Item Function Reference Manual
399
2
Inspecting and Measuring
External Reference Tables (Character Inspection)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
1 Chara. Num Get only 0 to 32
2 NG cause Get only 0x0000 to 0x000F
3 Read string Get only Character string
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 to 123 Dictionary unit number Set/Get
-1: OFF
0 to 9999
124 Inspection mode Set/Get
0: OCR
1: OCR + Count
2: OCV
125 Direction Set/Get
0: →
1: ↓
2: ←
3: ↑
126 Character output Set/Get
0: OFF
1: ON
127 Character output destination Set/Get
0: RS-232C/RS-422
1: Ethernet
129 Horizontal succession Set/Get 0 to 99
130 Vertical succession Set/Get 0 to 99
132
Dictionary candidate point
leve
l usage flag
Set/Get
0: Not used
1 : Used
133 Rough candidate Set/Get 0 to 100
134 Detail candidate Set/Get 0 to 100
135
Dictionary correlation usage
flag
Set/Get
0: Not used
1 : Used
136
Lower limit value of correlation
value
Set/Get 0 to 100
137 Upper limit of chara. Num Set/Get 1 to 32
138 Lower limit of chara. Num Set/Get 1 to 32
139 Verification string Set/Get Character string with 32 characters or less
140+N
(N=0 to 35)
Model 1 usage flag Set/Get
0: Not used
1 : Used
176+N
(N=0 to 35)
Model 2 usage flag Set/Get
0: Not used
1 : Used
212+N
(N=0 to 35)
Model 3 usage flag Set/Get
0: Not used
1 : Used
248+N
(N=0 to 35)
Model 4 usage flag Set/Get
0: Not used
1 : Used
284+N
(N=0 to 3)
Scene No. Set/Get
-1: Current scene
0 to 9999
288 Lower limit of stability Set/Get 0 to 100
