Barcode
448
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Barcode)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error(image format mismatch)
-11: Error(unregistered model)
-12: Error(insufficient memory)
-20: Error(other errors)
6 Decoded character count Get only Number of characters detected
7 Decoded character string Get only Character strings detected
8 Index Get only
0 to 127: Index matched as the resul
t
of comparison with the
classification comparison character strings
-1: Where there was no match with any of the index
co
mp
arison strings, or the index comparison string has not
been set up.
9 Integrated quality Get only 0 to 4
10 Integrated 1D Get only 0 to 4
11 Decode 1D Get only 0 to 4
12 Symbol contrast 1D Get only 0 to 4
13 Minimum reflection ratio 1D Get only 0 to 4
14 Minimum edge contrast 1D Get only 0 to 4
15 Modulation 1D Get only 0 to 4
16 Defect 1D Get only 0 to 4
17 Decodability 1D Get only 0 to 4
18 Additional 1D Get only 0 to 4
19 Integrated 2D Get only 0 to 4
20 Decode 2D Get only 0 to 4
21 RAP symbol contrast Get only 0 to 4
22
RAP minimum reflection
ratio
Get only 0 to 4
23
RAP minimum edge
contr
a
st
Get only 0 to 4
24 RAP modulation Get only 0 to 4
25 RAP defect Get only 0 to 4
26 RAP decodability Get only 0 to 4
27 RAP additional Get only 0 to 4
28 RAP overall quality Get only 0 to 4
29 Code word yield Get only 0 to 4
30 Unused error correction Get only 0 to 4
31 Decodability 1D Get only 0 to 4
32 Defect 1D Get only 0 to 4
33 Modulation 1D Get only 0 to 4
80 GS1 flag Get only
0: Normal
1: GS1 code
