Ec CornerFH/FZ5 Processing Item Function Reference Manual
197
2
Inspecting and Measuring
Output Parameters (Ec Corner)
Set how to treat the coordinates to be output to the external device as measurement results. This item can be
changed if necessary.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Key Points for Test Measurement and Adjustment (Ec Corner)
The following content is displayed in the "Detail result" area as text.
The image specified in the Sub-image number in image display setting is dis
played in the image display area.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
Setting item
Setting value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether
to output coordinate values to
external devices before or after the position compensation is applied.
Calibration
•[OFF]
•ON
Select whether to reflect the calibration in the values output to the
external
device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to overall
ju
dgemen
t
•[ON]
•OFF
Specify whether or not the judgement results of this processing unit is
reflected in the scene overall judgement.
Displayed items Description
Judge Judgement result
Corner X X Coordinate of measured corner
Corner Y Y coordinate of measured corner
Angle Formed angle of measured corner
Number of detections Number of detections of corner
Sub image. Explanation of image to be displayed
0 Measurement image
Parameter to be adjusted Troubleshooting
Measurement
Reduce the distance between the upper and lower limits of line length range for extracting
li
nes, to reduce false detections.
Raise the line connection level to prevent the lines constituting the corners to be detected from
being interrupted.
Set the narrowest possible conditions for extrac
ting c
orners, to reduce false detections.
