Omron fh-3 series User Manual

Precise Calibration
646
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Precise Calibration)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Precise Calibration)
Measurement items Character string Description
Judge JG Judgement result
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (not yet measured)
1: Judgement result OK
-1: Judgement result NG
103
Reflect to overall
j
udg
ement
Set/Get
0: ON
1: OFF
120
Coordinate indication
method
Set/Get
Select the grid point detection method.
0: Sampling
1: Pattern plate
121 Correction settings Set/Get
0: Corrected image not output
1: Corrected image output
183
Grid point average
re
petition count
Set/Get 1 to 10
240 Focal distance of lens [mm] Set/Get 3.0000 to 200.0000
241 CCD1 pixel size [μm] Set/Get 1.0000 to 15.0000
242 Plate height [mm] Set/Get -100.0000 to 100.0000
243 Workpiece height [mm] Set/Get -100.0000 to 100.0000
244 Depth settings Set/Get
0: Off
1: On
260 Margin/X maximum Get only -1.0000 to -1.0000
261 Margin/Y maximum Get only -1.0000 to -1.0000
