Sensitive SearchFH/FZ5 Processing Item Function Reference Manual
129
2
Inspecting and Measuring
Measurement Results for Which Output Is Possible (Sensitive Search)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Measurement items Character string Description
Judgement JG Judgement result
Correlation value CR Correlation value with the model
Deviation DV Deviation
Measurement coordinate X X X coordinate of the position where the model is detected
Measurement coordinate Y Y Y coordinate of the position where the model is detected
Measurement angle TH Angle of the position where the model is detected
Reference position X SX X coordinate of the reference positio
n of the registered model
Reference position Y SY Y coordinate of the reference position
of the registered model
Reference angle ST Angle of the registered model
Detection point coordinate X RX X coordinate of the registered model
Detection point coordinate Y RY Y coordinate of the registered model
NG sub-region CT NG region count
Sub-region Number AN Region number with the lowest correlation value
Sub-region Number(X) ANX X direction column number for the output region
Sub-region Number(Y) ANY Y direction line number for the output region
Sub-region Pos. X DX X coordinate of the detected sub-region
Sub-region Pos. Y DY Y coordinate of the detected sub-region
Correlation (sub-region N)
(N = 0 to 99)
CRN Correlation (sub-region N)
Deviation (sub-region N)
(N = 0 to 99)
DVN Deviation (sub-region N)
