Support Inspection and Measurement
Additional Explanation (Data Logging)
When 9 or More Data Items Are Output as One Record
Up to 8 Value can be output with one [Data Logging] Processing Item. When 9 or more data items are to be
output as 1 record, perform settings in the following manner.
• Registers two or more [Data Logging] units in one scene. (*1)
• Set [File name] of [Data Logging] so that it is identical. (*2)
• This prepares set up to attach "Record separator (CR+LF)" to the end of all data output. (*3)
Example) When outputting the coordinate data for 12 points acquired in two "Search" of
measurements performed on substrate arrangement in 1 record.
Unit 3 [Data logging]
setting details
Unit 4 [Data logging]
setting details
Remarks
<Condition setting> <Condition setting>
Output Destination
(File name)
datalog.csv
Output Destination
(File name)
datalog.csv
(*2)
Make the path and file name the
same.
Integer 8 Integer 8
Decimal 3 Decimal 3
Measurement ID ON Measurement ID OFF
Minus - Minus -
0 suppress OFF 0 suppress OFF
Field separator Comma Field separator Comma
Record separator Comma Record separator CR+LF
(*3)
Set "Record separator (CR+LF)" in
un
it 4 wh
ich contains the last data
<Output data> <Output data>
Calculation 0. U1.X (Search position X)
Calculation 1. U1.Y (Search position Y)
Calculation 2. U1.TH (Angle θ)
Calculation 3. U1.SX (reference X)
Calculation 4. U1.SX (reference Y)
Calculation 5. U1.ST (Reference angle θ)
Calculation 6. U2.X (Search position X)
Calculation 7. U2.Y (Search position Y)
Calculation 0. U2.TH (Search angle θ)
Calculation 1. U2.SX (reference X)
Calculation 2. U2.SY (reference Y)
Calculation 3. U2.ST (Reference angle θ)
The data not included in Unit 3 will be
ou
tp
ut as Calculation 0 to 3 in Unit 4
0. Camera Image Input
1. Search
(Search position X, Y, Search angle TH, Reference SX, SY, Ref. Angle ST)
2. Search
3. Data logging
4. Data logging
Output record:
YYYY-MM-DD_HH-MM-SS-MS,X,Y,TH,SX,SY,ST,X,Y,TH,SX,SY,ST+CR+LF
(*1)
1 Set up more than “data logging” Unit in one scene
(Search position X, Y, Search angle TH, Reference SX, SY, Ref. Angle ST)
Data of Unit 1 Data of Unit 2
