User DataFH/FZ5 Processing Item Function Reference Manual
649
4
Support Inspection and Measurement
Items Displayed in the Detail Result Area
The following measurement results are displayed in the “Detail result” area as text.
Items Displayed in the Image Display Area
You can specify a sub-image number to display the next image in the image display area.
Measurement Results For Which Output Is Possible (User Data)
The measurement results provided by user data are shown below. The measurement results appear in the
“Detail Result” area, and you can also use result output processing items to output the measurement results to
an external device.
Refer to the “External Reference Tables” for the parameter
s
that can be referenced, including measurement
results.
(Reference: External Reference Table (User Data) (p.649))
External Reference Table (User Data)
By specifying a number, you can access the following data from processing items that support processing unit
data setting/acquisition, and from control commands.
Displayed item Description
Judge Displays the judgement result for the processing unit.
Sub image number Description
0 The measurement image appears.
Measurement item Character string Description
Judge JG The judgement result for the processing unit
Setting data 00 to Setting
data 99
DT00 to DT99 Values of user data 00 to User data 99
• When a calculation expression is not set in the setting data
, the raw values of the user data can be acquired as
measurement results. When a calculation expression is set, you can acquire as measurement results the user data
values with the calculation results applied.
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
200+N
(N=0 to 99)
User Data Set/Get Expression character string
1000 to 1099 Calculation result Get only -999,999,999.9999 to 999,999,999.9999
