EC Circle Search
152
FH/FZ5 Processing Item Function Reference Manual
Output Parameters (EC Circle Search)
Specify how to treat the coordinates to be output to the external device as measurement results. This item can
be changed if necessary. Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify a value for the items.
Key Points for Test Measurement and Adjustment (EC Circle Search)
The following content is displayed in the "Detail result" area as text.
• After setting up the measurement parameters, changing the output parameters will cause measurement results to vary
accordingly. If the output parameters have been changed, re-specify the measurement, too.
Setting item
Set value
[Factory default]
Description
Output coordinates
• [After scroll]
• Before scroll
As measurement results, select whether to output coordinate values
to exte
rnal de
vices before or after the position deflection correction is
applied.
Calibration
• [OFF]
•ON
Select whether to reflect the calibration
in
the values output to the
external device as measurement results.
ON: Output the coordinates converted into actual dimensions.
OFF: Output the camera coordinate values.
Reflect to the overall
ju
dgemen
t
• [ON]
•OFF
Enables choosing whether or not the judgement results of this
processing unit is reflected in the scene overall judgment.
• For output coordinates and calibration, Reference: "Appendixes Measurement Mechanism Handling Coordinates" in
the "Vi
sion System FH/FZ5 Series User's Manual (Z365)"
Displayed item Description
Judge Judgement result
Position X X coordinate of the position wh
ere th
e model is detected
Position Y Y coordinate of the position where th
e model is detected
Evaluation Circle evaluated value of circles detected
Radius Radius of circles detected
Search count Quantity of circles detected
