Data Save
828
FH/FZ5 Processing Item Function Reference Manual
3 To display comments in the "Detail
result display" area, check "Comment
view".
Key Points for Test Measurement and Adjustment (Data Save)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following points.
Measurement Results for Which Output Is Possible (Data Save)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Data Save)
* Numeric data can be set by the processing item of the processing unit data setting.
Displayed items Description
Judge Judgement result
Save data N (N = 0 to 15) Stored data
State Parameter to be adjusted Troubleshooting
Saved data is updated
unintentionally.
-
Update can be controlled by setting the following flow.
Example)
0. Camera image input
1. Input condition branching
:
N. Measurement completion
N+1. Save data
Control the DI signal so that it branches to saving data when
up
dating saved data.
Measurement items Character string Description
Judge JG Judgement result
Save data N (N = 0 to 15) D00 to D15 Stored data
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 + N
(N = 0 to 15)
Expression result of
expre
ssion N
(N = 0 to 15)
Get only -999999999.9999 to 999999999.9999
120 + N
(N=0 to 15)
Save data calculation N Set/Get Exp. character string (*)
168 + N
(N=0 to 15)
Expressions comment N Set/Get Character string
200 + N
(N=0 to 15)
Comment view N Set/Get
0:OFF
1:ON
