Circular Scan Edge Position
268
FH/FZ5 Processing Item Function Reference Manual
Circular Scan Edge Position
This processing item detects the position of the circular measurement object by using the change in color within
the measurement region.
Used in the Following Case
• To obtain the center of the circle and the radius from multiple edges of a circular
measurement object
• Processing is different for color images and monochrome images. If the camera type, color camera, or monochrome
camera, was changed from a previous setup, a reset of some settings may be needed.
• Edge image measurement processing mechanism
Reference: "Appendixes Measurement Mechanism Edge Detection
Measurement" in the "Vision System FH/FZ5
Series User's Manual (Z365)"
Searches the edge with the change in color within the measurement region.
The edge can be detected by specifying the color to be detected.
To Next Page
