FH/FZ5 Processing Item Function Reference Manual
Settings Flow (Search)
Set up searches according to the following flow.
List of Search Items
Item name Description
Model register
This item registers the pattern characteristic of the
measurement image as a model.
Model parameter values can be changed as needed to address unstable measurement results or to
incre
ase the processing speed. Normally, the factory default value will be used.
Reference: Model Registration (Search) (p.97)
Region setting
This item is used to set up the me
asurement area.
Instead of measuring the entire input image, narrowing
the measurement area shortens the processing
time.
Reference: Region Setting (Search) (p.99)
Detection point
This item can be changed if necessary. Specify a posi
tion in the model that should be used as the
detection coordinates during measurement. Usually, the central position of the set model is registered as
the detection coordinates.
Reference: Detection Point (Search) (p.100)
Ref. setting
This item can be changed if necessary. Specify the reference
position within the camera's field of view.
Reference: Reference Setting (Search) (p.101)
Measurement
This item specifies the judgement conditi
on for measurement results. Specify the criteria to judge the
measurement result if the X and Y coordinates and the correlation with the model are OK.
Reference: Measurement Parameters (Search) (p.102)
Output
p
a
rameter
This item can be changed if necessary. Normally, the
factory default value will be used.
Use the output parameter to specify how to handle the coordi
nates.
Reference: Output Parameters (Search) (p.104)
Necessary Steps Optional Steps
Verify/Adjust results
▲
Model Registration (Search)
▲
Region Setting (Search)
▲
Measurement Parameters (Search)
▲
Detection Point (Search)
▲
Reference Setting (Search)
▲
Output Parameters (Search)
Start
Settings completed
Test measurement
