Omron fh-3 series User Manual

PLC Master Calibration
774
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (PLC Master Calibration)
The following values can be output using processing items related to results output. It is also possible to refer to
measurement values from expressions and other processing units.
External Reference Tables (PLC Master Calibration)
Measurement items
Character
string
Description
Judge JG Judgment result
NG cause CNG
NG cause
-1: Setting NG
-2: Sequence NG
-3: Mobility NG
-4: Calibration NG
-5: Evaluation NG
-6: Sampling NG
-100: Other NG
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement(unmeasured)
1: Judgement result OK
-1: Judgement result NG
18 Next Calibration Operation Get only ---
19 Calibration step No. Get only ---
20 NG cause Get only ---
120 Calibration target flag Set/Get
0: Not process
1: Process
121 The number of translation Set/Get 2 to 100
122 The number of rotational motion Set/Get 2 to 100
123 Scene No. Set/Get
-1: Current scene refered
0 to 9,999: Pointed scene refered
124 Unit No. Set/Get
-1: No reference
0 to 9,999: Pointed unit refered
125 Calibration type Set/Get
0: Normal
1: Easy
200 + N × 10
(N: 0 to 7)
Calibration target flag of data N Set/Get
0: No
1: Yes
201 + N × 10
(N: 0 to 7)
Position X of data N Set/Get Exp. character string
202 + N × 10
(N: 0 to 7)
Position Y of data N Set/Get Exp. character string
203 + N × 10
(N: 0 to 7)
Judge expression of data N Set/Get Exp. character string
204 + N × 10
(N: 0 to 7)
Upper limit of judge condition of data N Set/Get -999,999,999.9999 to 999,999,999.9999
205 + N × 10
(N: 0 to 7)
Lower limit of judge condition of data N Set/Get -999,999,999.9999 to 999,999,999.9999
1000 + N × 10
(N: 0 to 99)
X-direction movement of parallel position
No
.N
Set/
Get -999,999,999.9999 to 999,999,999.9999
