2D Code
422
FH/FZ5 Processing Item Function Reference Manual
Results Settings (2D Code)
Results can be classified according to the judgement results.
1 In the Item Tab area, click [Result setting].
2 Register the character string that will be the reference for classification.
3 If necessary, set the quality display for
the Detail Result Pane.
Output Parameters (2D Code)
Select how measurement results are output to an external device. This item can be changed if necessary.
Normally, the factory default value will be used.
1 Click [Output parameter] in the Item Tab area.
2 Specify each of the following items.
Integrated quality
(lower limit value) (only
when the read mode is
Normal)
0.0 to 4.0
[0]
Specify the integrated quality to be judged as OK.
It can be set when the code type is DataMatrix, PDF417 or
MicroPDF
417
.
Setting item Set value Description
Classification string - Set the Comparison character string. Up to 652 characters can be set.
'*' '?' is treated as
chara
c
ter data.
• Checked
• [Unchecked]
Checked: '*' and '?' are handled as normal characters.
Unchecked: '*' and '?' are handled as special characters.
'*': Substitution for character string (with 0 or more characters)
'?': Substitution for 1character
Setting item Set value Description
Code quality display
• Checked
• [Unchecked]
Select whether or not to display the integrated quality.
All of the items cannot be displayed due to the displayed items
i
s too many in the Detail Result Pane.
When display all of the items, change the Detail Result Pane size.
For details, refer to Arranging Windows in the V
i
sion System FH/FZ5 Series User's Manual (Cat. No. Z365).
Setting item
Set value
[Factory default]
Description
Reflect to overall judgement
•[ON]
•OFF
Enables choosing whether or not the j
udgement results of this
processing unit is reflected in the scene overall judgement.
Character output
•Checked
• [Unchecked]
Set whether to output character strings.
Setting item Set value Description
To Next Page
