Labeling
336
FH/FZ5 Processing Item Function Reference Manual
Region Setting (Labeling)
This item is used to set up the measurement area. It is possible to measure the entire input image, but restricting
the range enables accurate measurement in a short period of time.
Use a rectangle, straight line, circle (ellip
se),
wide circle, or polygon to specify a measurement region for
[Labeling].
1 In the Item Tab area, click [Region setting].
2 Use the Drawing tools to specify the measurement region.
3 In the figure setting area, specify a region to be measured.
4 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
5 If necessary, in the "Display setting" area, set up display settings for the images displayed in
the Image Display area.
For color cameras:
For monochrome cameras:
Setting item
Set value
[Factory default]
Description
Extract image
• [Checked]
• Unchecked
If you place a check at this option, image
set with the color specification
are displayed.
Setting item
Set value
[Factory default]
Description
Binary image
• [Checked]
• Unchecked
The image is displayed in binary with black and white.
To Next Page
