Fine Matching
388
FH/FZ5 Processing Item Function Reference Manual
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
When non-existent defects are detected around the boundary
When noise is detected as defects/defect
s cannot be detected
Measurement object near plain area
When the processing speed is slow
Measurement Results for Which Output Is Possible (Fine Matching)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Parameter to be adjusted Remedy
Model Uncheck "Boundary inspection".
Measurement Set "Labeling" as the "Inspection".
Parameter to be adjusted Remedy
Diff. image disp. Adjust "Difference".
Parameter to be adjusted Remedy
Diff. image disp. Uncheck "Normalization".
Parameter to be adjusted Remedy
Model Uncheck "Boundary inspection".
Measurement Set "Labeling" as the "Inspection".
Measurement items Character string Description
Judgement JG Judgement result
Quantity DA Number of labeling
Area AR Area
Defect position X X coordinate of center of gravity po
sition of measured defects
Defect position Y Y coordinate of center of gravity po
sition of measured defects
