Barcode
444
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Barcode)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
Measurement items Character string Description
Judgement JG Judgement result
Number of decoded character DN Number of characters detected
Index IDX
Index matched as the result of co
mparison with the
classification comparison character strings
Integrated quality GT Integrated quality
Integrated quality GB0 Integrated quality 1D
Decode GB1 Decode 1D
Symbol contrast GB2 Symbol contrast 1D
Minimum reflection ratio GB3 Minimum reflection ratio 1D
Minimum edge contrast GB4 Minimum edge contrast 1D
Modulation GB5 Modulation 1D
Defect GB6 Defect 1D
Decodability GB7 Decodability 1D
Additional GB8 Additional 1D
Integrated quality GP0 Integrated quality 2D
Decode GP1 Decode 2D
RAP symbol contrast GP2 RAP symbol contrast
RAP minimum reflection ratio GP3 RAP minimum reflection ratio
RAP minimum edge contrast GP4 RAP minimum edge contrast
RAP modulation GP5 RAP modulation
RAP defect GP6 RAP defect
RAP decodability GP7 RAP decodability
RAP additional GP8 RAP additional
RAP overall quality GP9 RAP overall quality
Code word yield GP10 Code word yield
Unused error correction GP11 Unused error correction
Decodability GP12 Decodability 2D
Defect GP13 Defect 2D
Additional GP14 Modulation 2D
