Precise DefectFH/FZ5 Processing Item Function Reference Manual
377
2
Inspecting and Measuring
Measurement Results for Which Output Is Possible (Precise Defect)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Precise Defect)
Measurement items Character string Description
Judgement JG Judgement result
Defect F Measured defect level
Measurement coordinate X X X Coordinate of measured defect position
Measurement coordinate Y Y Y coordinate of measured de
fe
ct position
Defect area AR The measured maximum defect area
Gravity X GX The center of gravity X coordinates of the measured maximum defect area
Gravity Y GY The center of gravity Y coordinates of
the measured maximum defect area
Defect number NM Number of measured defects
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Defect Get only 0 to 999
6 Position X Get only 0 to 999999999.9999
7 Position Y Get only 0 to 999999999.9999
8 Area Get only 0 to 999999999.9999
9 Gravity X Get only 0 to 999999999.9999
10 Gravity Y Get only 0 to 999999999.9999
11 Defect number Get only 0 to 2500
103
Reflect to overall
j
udgement
Set/Get
0: ON
1: OFF
120 Size X Set/Get 4 to 64
121 Size Y Set/Get 4 to 64
122 Sampling interval X Set/Get 1 to 64
123 Sampling interval Y Set/Get 1 to 64
124 Comparing interval X Set/Get 1 to 32
125 Comparing interval Y Set/Get 1 to 32
126
Detection object color
(for monochrome cameras
on
l
y)
Set/Get
0: Both white/black
1: White
2: Black
127 Defect detection direction X Set/Get
0: OFF
1: ON
128 Defect detection direction Y Set/Get
0: OFF
1: ON
