Color Data
314
FH/FZ5 Processing Item Function Reference Manual
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
When the processing speed is slow
Measurement Results for Which Output Is Possible (Color Data)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
For color cameras
For monochrome cameras
External Reference Tables (Color Data)
Parameter to be adjusted Remedy
Measurement For a color camera, place a check at [Normalization].
Parameter to be adjusted Remedy
Region setting Set the measurement region to be as small as possible.
Measurement items Character string Description
Judge JG Judgement result
R average AR R (red) element average value
G average AG G (green) element average value
B average AB B (blue) element average value
Color difference AD
The color difference between the average color and reference color in the
measureme
n
t region
Color deviation DV Color deviation in the measurement region
H average AH Average H (Hue) component value
S average AS Average S (Saturation) component value
V average AV Average V (Value) component value
Measurement items Character string Description
Judge JG Judgement result
Density average AD
Difference between the average density and the reference density in the
measureme
nt region
Density deviation DV Color deviation in the measurement region
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5
Average R component
value
Get only 0 to 255
