Scan Edge Position
244
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (Scan Edge Position)
Set the scan edge position with the following steps.
Item List for Scan Edge Position
Item name Description
Region setting
This item is used to set up the measurement area.
Reference: Region Setting (Scan Edge Position) (p.245)
Edge color
(for color cameras only)
If the color of the edges to be detected is decided, specify the information for the edge color to be
de
te
cted.
Reference: Edge Color Specification - For Color Cameras Only (Scan Edge Position) (p.246)
Ref. setting
This item can be changed if necessary.
The edge position measured once is registered when the region is set.
Reference: Reference Setting (Scan Edge Position) (p.247)
Measurement
This item changes the measurement parameter as n
e
cessary when the measurement result is
unstable.
The displayed items depend on whether your camera
is
a color or monochrome camera. Normally,
the factory default value will be used.
Reference: Measurement Parameters (Scan Edge Positions) (p.248)
Judgement
This item specifies the judgement co
ndi
tion for measurement results.
Reference: Judgement Conditions (Scan Edge
Position) (p.251)
Output parameter
This item can be changed if necessary. Normally, the factory default value may be used.
Select the measurement result coordinates and set how to handle the coordinates.
Reference: Output Parameters (Scan Edge Position) (p.252)
Necessary Steps Optional Steps
Verify/Adjust results
▲
Region Setting (scan edge position)
▲
Judgement Conditions (scan edge position)
Start
Settings completed
Test measurement
▲
Edge Color Specification – For Color
Cameras Only (scan edge position)
▲
Reference Setting (scan edge position)
▲
Measurement Parameters (scan edge position)
▲
Output Parameters (scan edge position)
