FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Statistics)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Statistics)
Measurement items Character string Description
Judge JG Judgement result
Calculated time CT Count
Statistic value N
(N = 0 to 7)
DTN (N = 0 to 7) Statistical processing result 0 to 7
Valid data N
(N = 0 to 7)
OCN (N = 0 to 7) Number of valid statistical processing data 0 to 7
Maximum N
(N = 0 to 7)
MXN (N = 0 to 7) Stored data maximum value 0 to 7
Minimum N
(N = 0 to 7)
MNN (N = 0 to 7) Stored data minimum value 0 to 7
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Calculated time Get only 0 to 100
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Maximum number of stored data Set/Get 1 to 100
121 Data No. Set/Get 0 to 7
122 Calculation timing Set/Get 0 to 1
131 + N × 10
(N = 0 to 7)
Data expression N Set/Get Exp. character string
132 + N × 10
(N = 0 to 7)
Data N Upper limit of the judgement
range
Set/Get -999999999.9999 to 999999999.9999
133 + N × 10
(N = 0 to 7)
Data N Lower limit of the judgement
range
Set/Get -999999999.9999 to 999999999.9999
134 + N × 10
(N = 0 to 7)
Data N Upper limit of the display
range
Set/Get -999999999.9999 to 999999999.9999
135 + N × 10
(N = 0 to 7)
Data N Upper limit of the display
range
Set/Get -999999999.9999 to 999999999.9999
136 + N × 10
(N = 0 to 7)
Amount of change in data N display
range
Set/Get 1 to 1000000
137 + N × 10
(N = 0 to 7)
Data N Measurement value Set/Get -999999999.9999 to 999999999.9999
138 + N × 10
(N = 0 to 7)
Expressions comment N Set/Get Character string
1000 + N × 10
(N = 0 to 7)
Measurement Set/Get -999999999.9999 to 999999999.9999
1001 + N × 10
(N = 0 to 7)
Statistical value Set/Get -999999999.9999 to 999999999.9999
