Unit Calculation Macro
618
FH/FZ5 Processing Item Function Reference Manual
Unit Calculation Macro
You can perform calculations, as well as setting/acquiring.
This function is convenient when
the user wants to calculate a value using an original calculation formula or
change the set value or system data of a processing item.
Used in the Following Case
• Calculations that use multiple processing items including looping and conditional branch can
be consolidated into one.
Example) When you want to use a different calculation formula depending on the condition
• Using a flow: Realized by combining Conditional Branch and Ca
lculation.
• Using unit calculation macro: Define in a unit calculation macro
processing item a calculation
processing that uses a calculation formula appropriate for each condition.
A flow can be made simpler using unit calculation macro.
• A set of multiple processing items can be consolidated into one processing when, for
example, changing the settings of multiple processing depending on the condition.
Example) When you want to change the labeling extraction condition depending on the sorting result
• Using a flow: Realized by combining Conditional Branch, Calculation and Set
Unit Data.
• Using unit calculation macro: Register a reference var
iable representing the labeling extraction
conditions and define a processing that assigns a value to the variable
according to each condition.
A flow can be made simpler using unit calculation macro.
For the specifications of the Unit Calcula
t
ion Macro, and for details on Unit Calculation Macro settings, refer to
the following:
Reference: De
scription of the Setting Screen of the “Unit Calculation Macro” Processing Item and How to
Configure Settings in the V
ision System FH/FZ5 Series Macro Customize Functions Programming Manual (Cat.
No. Z367)
