Scan Edge PositionFH/FZ5 Processing Item Function Reference Manual
255
2
Inspecting and Measuring
External Reference Tables (Scan Edge Position)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
1 Peak edge position X Get only 0 to 99999.9999
2 Peak edge position Y Get only 0 to 99999.9999
3 Bottom edge position X Get only 0 to 99999.9999
4 Bottom edge position Y Get only 0 to 99999.9999
5 Edge position X Ave. Get only -1 to 99999.9999
6 Edge position Y Ave. Get only -1 to 99999.9999
7 Long distance Max. Get only -1 to 99999.9999
8 Long distance Min. Get only -1 to 99999.9999
9 Short distance Max. Get only -1 to 99999.9999
10 Short distance Min. Get only -1 to 99999.9999
11 Deviation Get only -1 to 99999.9999
12 Angle Get only -180 to 180
13 Lost point Get only 0 to 100
14 Linear coefficient A Get only -99999.9999 to 99999.9999
15 Linear coefficient B Get only -99999.9999 to 99999.9999
16 Linear coefficient C Get only -99999.9999 to 99999.9999
17 Reference X
*1
Get only 0 to 99999.9999
18 Reference Y
*1
Get only 0 to 99999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
j
udg
ement
Set/Get
0: ON
1: OFF
120 Edge color specification Set/Get
0: OFF
1: ON
121 Edge color R Set/Get 0 to 255
122 Edge color G Set/Get 0 to 255
123 Edge color B Set/Get 0 to 255
124 Difference R Set/Get 0 to 127
125 Difference G Set/Get 0 to 127
126 Difference B Set/Get 0 to 127
127 Detection mode Set/Get
0: Color IN
1: Color OUT
129 Reference X
*2
Set/Get 0 to 99999.9999
130 Reference Y
*2
Set/Get 0 to 99999.9999
