OCR
458
FH/FZ5 Processing Item Function Reference Manual
Region Setting (OCR)
For the measurement region, set the region of the image over which you want to detect characters..
By narrowing the measurement region (as opposed to measuring the entire input image), this function allows
you to shor
ten the processing time.
1 In the Item Tab area, click [Region setting].
2 Click [Edit].
3 Set the region over which the model is to be searched for.
4 Click [OK] in the Figure setting area.
• [OK]: Changes the settings and returns to the previous menu.
• [Cancel]: Changes are discarded. R
eturns to the previous menu.
• [Apply]: Updates the settings without leaving edit window.
• The size of the measurement region should be at least 30 x 30 pixels.
• The measurement region should not include characters tha
t exceed 32 characters x four lines.
Important
