Labeling
346
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Labeling)
Feature quantity 0 to 7 [1] FDA1 to FDH1 Measurement date of feature quantity
Feature quantity 0 to 7 [2] FDA2 to FDH2 Measurement date of feature qua
ntity
•
•
•
•
•
•
•
•
•
Feature quantity 0 to 7 [99] FDA99 to FDH99 Measurement date of fe
ature quantity
No. Data name Set/Get Data range
0 Judge Get
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
-10: Error (image format mismatch)
-11: Error (unregistered model)
-12: Error (Insufficient memory)
-20: Error (Other error)
5 Number of labels Get
0 to 2500 (For FZ5-3xx, FZ5-6xx)
0 to 9999 (For FH-1xxx, FH-3xxx,
FZ5-8x
x, FZ5-11xx,
FZ5-12xx)
6 Area Get 0 to 999999999.9999
7 Gravity X Get -99999.9999 to 99999.9999
8 Gravity Y Get -99999.9999 to 99999.9999
9 Reference area Get 0 to 999999999.9999
10 Reference X
*1
Get -99999.9999 to 99999.9999
11 Reference Y
*1
Get -99999.9999 to 99999.9999
50 + N (N=0 to 7) Feature data N Get -999999999.9999 to 999999999.9999
101 Output coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103 Reflect to overall judgement Set/Get
0: ON
1: OFF
120 Max. color difference Set/Get 0 to 359
121 Min. color difference Set/Get 0 to 359
122 Max. saturation Set/Get 0 to 255
123 Min. saturation Set/Get 0 to 255
124 Max. brightness Set/Get 0 to 255
125 Min. brightness Set/Get 0 to 255
126 Extract image Set/Get
0: OFF
1: ON
127 Background color Set/Get
0: Black
1 : White
2: Red
3: Green
4: Blue
128 Reference area Set/Get 0 to 999999999
129 Reference X
*2
Set/Get 0 to 99999.9999
Measurement items Character string Description
