LabelingFH/FZ5 Processing Item Function Reference Manual
347
2
Inspecting and Measuring
130 Reference Y
*2
Set/Get 0 to 99999.9999
131
Color inv.
(reverse for monochrome)
Set/Get
0: OFF
1: ON
132 Filling up holes Set/Get
0: OFF
1: ON
133 Outside trimming Set/Get
0: OFF
1: ON
134
Upper limit of the object area
range
Set/Get 0 to 999999999
135
Lower limit of the object area
range
Set/Get 0 to 999999999
136 Sort condition Set/Get
0: Area ascending
1: Area descending
2: X-coordinate ascending
3: X-coordinate descending
4: Y-coordinate ascending
5: Y-coordinate descending
6: Elliptic major axis ascending
7: Elliptic major axis descending
8: Elliptic minor axis ascending
9: Elliptic minor axis descending
10: Elliptic ratio ascending
11: Elliptic ratio descending
12: Rectangle width ascending
13: Rectangle width descending
14: Rectangle height ascending
15: Rectangle height descending
16: Rectangle X1 ascending
17: Rectangle X1 descending
18: Rectangle Y1 ascending
19: Rectangle Y1 descending
20: Perimeter ascending
21: Perimeter descending
22: Circularity ascending
23: Circularity descending
24: Fit rect major axis ascending
25: Fit rect major axis descending
26: Fit rect minor axis ascending
27: Fit rect minor axis descending
28: Fit rect ratio ascending
29: Fit rect ratio descending
30: Inscribed circle X ascending
31: Inscribed circle X descending
32: Inscribed circle Y ascending
33: Inscribed circle Y descending
34: Inscribed circle R ascending
35: Inscribed circle R descending
36: Circum. circle X ascending
37: Circum. circle X descending
38: Circum. circle Y ascending
39: Circum. circle Y descending
40: Circum. circle R ascending
41: Circum. circle R descending
42: Number of holes ascending
43: Number of holes descending
No. Data name Set/Get Data range
