Circle Angle
492
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Circle Angle)
The following content is displayed in the "Detail result" area as text.
Key Points for Adjustment
Select the adjustment method referring to the following points.
When the measurement results are unstable
When the processing speed is slow
Measurement Results for Which Output Is Possible (Circle Angle)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
[Note 1]: Since measuring is performed at the same position
every time for Circle Angle, "Center X = Reference
SX, Center Y = Reference SY".
Displayed items Description
Judge Judgement result
Rotation angle Measured Angle
Center position X Center position X of circle in measurement results
Center position Y Center position Y of circle in measurement results
Reference angle Angle of the circle drawn as the measurement region
Reference X Reference position X of the circle drawn as the measurement region
Reference Y Reference position Y of the circle drawn as the measurement region
Parameter to be adjusted Remedy
Region setting Specify a smaller value for the "Skipping angle".
Measurement flow
When the center position of measurement objects is not fixed,
add position compensation to
the flow so that the central coordinates of the measurement objects give a fixed position.
Parameter to be adjusted Remedy
Region setting
Specify a larger value for the "Skipping angle".
Set the "Mode" to "Edge" or "Defect".
Measurement items Character string Description
Judgement JG Judgement result
Center position X X Center position X of circle in measurement results
Center position Y Y Center position Y of circle in measurement results
Rotation angle TH
Angle of measurement results
Output range -180° to 180°
Reference position X SX
Reference position X of the circle drawn as the measurement region
[
N
ote 1]
Reference position Y SY Reference Y of the circle drawn as the measuremen
t reg
ion [Note 1]
Reference angle ST Angle drawn as the measurement region
