Image Subtraction
562
FH/FZ5 Processing Item Function Reference Manual
External Reference Tables (Image Subtraction)
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
120 Boundary inspection Set/Get
0: OFF
1: ON
121 Boundary level Set/Get 0 to 9
122 Normalization Set/Get
0: OFF
1: ON
123 Perturbation processing Set/Get
0: OFF
1: ON
124 Difference Set/Get 0 to 255
125 Model register Get only
0: Not registered
1: Registered
126 Fill profile color R Set/Get 0 to 255
127 Fill profile color G Set/Get 0 to 255
128 Fill profile color B Set/Get 0 to 255
129 Extract image Set/Get
0: OFF
1: ON
130 Operation mode Set/Get
0: Always extract differences
1: Register at DI input
2: Switch at every measurement
131 Model registration DI input Set/Get 0 to 31
132 Next measurement processing Set/Get
0: Model
1: Difference extraction
