Label Data
352
FH/FZ5 Processing Item Function Reference Manual
Settings Flow (Label Data)
Set up the label data with the following steps.
List of Label Data Items
Setting (Label Data)
Specify the unit number and label number of the unit set for labeling reference. In addition, specify the
judgement conditions for measurement results.
After changing a setting, check wheth
e
r measurement can be done properly by performing an actual
measurement.
1 In the Item Tab area, click [Setting].
2 In the "Label setting" area, specify each
item.
Item name Description
Setting
Specify the unit number and label nu
mber of the processing unit that is designated as the reference
object.
In addition, specify the judgement con
d
itions for measurement results. Specify the upper and lower
limit values for the area and the gravity center X/Y.
Reference: Setting (Label Data) (p.352)
Output
pa
r
ameter
This item can be changed if necessary. Normally, the factory default value will be used.
Use the output parameter to specify how to hand
le the coordi
nates.
Reference: Output Parameters (Label Da
ta) (p.353)
Setting item
Set value
[Factory default]
Description
Label unit [None] to 9999
Specify the number of the unit for which the
reference object processing
item has been set up. As an option, display the number of the unit for
which the following processing items have been set up.
• Labeling
Label No.
[0] to 2499
(For FZ5-3xx, FZ5-
6xx
)
[0] t
o 9998
(For FH-1xxx, FH-
3xx
x
, FZ5-8xx, FZ5-
11xx, FZ5-12xx)
Specify the number of the label for th
e
reference object.
Necessary Steps Optional Steps
Verify/Adjust results
▲
Setting (Label Data)
Start
Settings completed
Test measurement
▲
Output Parameters (Label Data)
