Control Flow PLC LinkFH/FZ5 Processing Item Function Reference Manual
847
5
Branch
Settings Flow (Control Flow PLC Link)
Set up control flow PLC link according to the following steps.
List of Control Flow PLC Link Items
The following items can be set in control flow PLC link.
Settings (Control Flow PLC Link)
Set communication and timeout conditions for controlling the measurement flow.
1 In the Item Tab area, click [Setting].
2 In the “Communication method” area, specify a value for each item.
Item name Description
Setting
Set communication and timeout conditions for controlling the measurement flow.
Reference: Settings (Control Flow PLC Link) (p.847)
Output
p
arameter
You can set this item to change the output parameters.
Set the conditions and parameters for outputting me
asurement results to other processing units or
external devices.
Reference: Measurement Results for Which Output Is Possible
(Control Flow PLC Link) (p.849)
Setting item
Setting value
[Factory default]
Description
Communication method
[RS-232C/RS-422]
Ethernet
Select the communication method used for controlling
the measuremen
t flow from an external device.
Necessary Steps Optional Steps
Check results/adjust parameters
Settings (Control Flow PLC Link)
Output Parameters (Control Flow PLC Link)
Start
Settings completed
Test measurement
