Detection Point
810
FH/FZ5 Processing Item Function Reference Manual
Detection Point
Obtains position/angle information by referring to the coordinate values measure with the Measurement
Processing Unit. Measurement can be performed based on precise detection points and reference position data
by making the Measurement Processing Unit with the detection point and reference position data refer to the
Detection Point Processing Unit.
Used in the Following Case
• When using the measurement result of another Processing Unit as a detection point
Before changing the [Search] detection points
Change
After changing the [Search] detection points
Example) Change the search detection points based on the measurement result of
an area gravity center.
Detection point
