Control Flow Normal
844
FH/FZ5 Processing Item Function Reference Manual
Key Points for Test Measurement and Adjustment (Control Flow Normal)
You can adjust the parameters while you perform test measurements and check the measurement results to
increase the measurement precision and speed.
Select the adjustment method by considering the following point.
Check the measurement results that can be displayed and
outp
ut in “Measurement Results for Which Output Is
Possible”.
Items Displayed in the Detail Result Area
The following measurement results are displayed in the “Detail result” area as text.
Items Displayed in the Image Display Area
You can specify a sub-image number to display the next image in the image display area.
Measurement Results for Which Output Is Possible (Control Flow Normal)
Measurement results in control flow normal are as shown below. The measurement results appear in the “Detail
Result” area, and you can also use result output processing items to output the measurement results to an
external device.
Refer to the “External Reference Tables” for the parameter
s
that can be referenced, including measurement
results.
(Reference: External Reference Table (Control Flow Normal) (p.845))
Displayed item Description
Judge Displays the judgement result for the processing unit.
Sub image number Description
0 The measurement image appears.
Measurement item Character string Description
Judge JG The judgement result for the processing unit
