Position CompensationFH/FZ5 Processing Item Function Reference Manual
511
3
Compensate image
Key Points for Test Measurement and Adjustment (Position Compensation)
The image specified in the Sub-image number in image display setting is displayed in the image display area.
Measurement Results for Which Output Is Possible (Position Compensation)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Position Compensation)
Sub image number. Explanation of image to be displayed
0 After compensation
1 Before compensation
Measurement items Character string Description
Judge JG Judgement result
Scroll X DX Scroll X
Scroll Y DY Scroll Y
Scroll θ DT Scroll θ
Measurement coordinate X X Measured value X coordinate
Measurement coordinate Y Y Measured value Y coordinate
Measurement angle θ TH Measure angle θ
Reference position X SX Reference X coordinate
Reference position Y SY Reference Y coordinate
Reference angle θ ST Reference angle θ
No. Data name Set/Get Data range
0 Judge Get only
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Scroll X Get only -99999.9999 to 99999.9999
6 Scroll Y Get only -99999.9999 to 99999.9999
7 Scroll θ Get only -999.9999 to 999.9999
8 Position X Get only 0 to 99999.9999
9 Position Y Get only 0 to 99999.9999
10 Measurement θ Get only -360 to 360
11 Reference X Get only -99999.9999 to 99999.9999
12 Reference Y Get only -99999.9999 to 99999.9999
13 Reference θ Get only -999.9999 to 999.9999
120 Interpolation Set/Get
0: None
1: Bilinear
121 Method Set/Get
0: 1 unit scroll
1: 2 unit scroll
2: Expression
3: Reset scroll
122 Scroll target Set/Get
0: Camera image
1: Prev. unit image
