Vision Master CalibrationFH/FZ5 Processing Item Function Reference Manual
745
4
Support Inspection and Measurement
Settings Flow (Vision Master Calibration)
Set the image master calibration with the following steps.
List of Vision Master Calibration Items
Item name Description
Machine setting
Select a processing item (stage data or robot data) under
which external device information needed for
calculation of axis movement amount is held.
Reference: Machine Setting (Vision Master Cali
bration
) (p.746)
Calibration
This item sets data related to calibration. Sets the numbe
r of calibration data to be created and the
measurement processing items to be used for sampling in the arithmetic expression. Also sets the
output method for the calculated axis movement amount.
Reference: Calibration (Vision Master Calibration) (p.746)
Sampling setting
This item sets data related to sampling.
Also makes the sampling settings for the initial calibration and this calibration.
Reference: Sampling Setting (Vision Master Calibration) (p.750)
Calibration result
This item confirms the cal
ibratio
n data you created. The calibration data can be adjusted directly using
the Edit function.
It is also possible to confirm the sampling data used for the calculation.
Reference: Calibration Result (Vision Master Cali
bration) (p.756)
Make sure to set Set as necessary.
Check results/make adjustments
Start
▲
Calibration
(Vision Master Calibration)
▲
Sampling Setting
(Vision Master Calibration)
Settings complete
Test measurement
▲
Calibration result
(Vision Master Calibration)
▲
Machine Setting
(Vision Master Calibration)
To Next Page
