Label Data
354
FH/FZ5 Processing Item Function Reference Manual
Measurement Results for Which Output Is Possible (Label Data)
The following values can be output using processing items related to results output. It is also possible to
reference measurement values from expressions and other processing units.
External Reference Tables (Label data)
Measurement items Character string Description
Judge JG Judgement result
Label No. LN Label No.
Area AR Area
Gravity X-coordinate X Center of gravity X position
Gravity Y-coordinate Y Center of gravity Y position
No. Data name Set/Get Data range
0 Judge Get
0: No judgement (unmeasured)
1: Judgement result OK
-1: Judgement result NG
5 Label No. Get
0 to 2499 (For FZ5-3xx, FZ5-6xx)
0 to 9998 (For FH-1xxx, FH-3xxx, FZ5-8xx, FZ5-11xx, FZ5-
12xx)
6 Area Get 0 to 999999999.9999
7 Gravity X Get -99999.9999 to 99999.9999
8 Gravity Y Get -99999.9999 to 99999.9999
101 Output Coordinates Set/Get
0: After scroll
1: Before scroll
102 Calibration Set/Get
0: OFF
1: ON
103
Reflect to overall
j
udg
ement
Set/Get
0: ON
1: OFF
120 Label unit Set/Get
-1: None
0 to 9999
121 Label No. Set/Get
0 to 2499 (For FZ5-3xx, FZ5-6xx)
0 to 9998 (For FH-1xxx, FH-3xxx, FZ5-8xx,
FZ5-11xx, FZ5-
12xx)
122 Upper limit of the area Set/Get 0 to 999999999.9999
123 Lower limit of the area Set/Get 0 to 999999999.9999
124 Upper limit of gravity X Set/Get -99999.9999 to 99999.9999
125 Lower limit of gravity X Set/Get -99999.9999 to 99999.9999
126 Upper limit of gravity Y Set/Get -99999.9999 to 99999.9999
127 Lower limit of gravity Y Set/Get -99999.9999 to 99999.9999
